type series
Fibre-insulated, high-temperature chamber furnace, Tmax. 1820°C, 3-52,5l with extremely short heating up - and cooling down cycles
| model | liters | T max in °C | Inside dimensions mm (w x h x d) | kW |
|---|---|---|---|---|
| HT 1400 | 4,0 | 1400 | 130 x 190 x 160 | 3,5 |
| HT 1400 M | 12,5 | 1400 | 250 x 200 x 250 | 6,0 |
| HT 1400 G | 26,0 | 1400 | 250 x 350 x 300 | 9,0 |
| HT 1400 GT | 52,5 | 1400 | 250 x 700 x 300 | 16,0 |
| HT 1600 | 4,0 | 1600 | 130 x 190 x 160 | 3,5 |
| HT 1600 M | 12,5 | 1600 | 250 x 200 x 250 | 6,0 |
| HT 1600 G | 26,0 | 1600 | 250 x 350 x 300 | 9,0 |
| HT 1600 GT | 26,0 | 1600 | 250 x 350 x 300 | 9,0 |
| HT 1800 | 4,0 | 1750 | 130 x 190 x 160 | 3,5 |
| HT 1800 M | 4,0 | 1750 | 130 x 190 x 160 | 3,5 |
| HT 1800 G | 4,0 | 1750 | 130 x 190 x 160 | 3,5 |
| HT 1800 GT | 4,0 | 1750 | 130 x 190 x 160 | 3,5 |
| HT 1800 Plus | 4,0 | 1820 | 130 x 190 x 160 | 3,5 |
| HT 1800 M Plus | 4,0 | 1820 | 130 x 190 x 160 | 3,5 |
| HT 1800 G Plus | 4,0 | 1820 | 130 x 190 x 160 | 3,5 |
| HT 1800 GT Plus | 4,0 | 1820 | 130 x 190 x 160 | 3,5 |
*Customized HT can be done up to 500 dm³
The protective gas – and vacuum tight, all-round reinforced inside casing is cooled by a fan so as not to exceed an outside wall temperature of the housing of 180 °C, also during continuous operation
The correspondingly designed outside housing remains cold (max. 40 °C above room temperature), except the door front panel. The vacuum tight swivelling door with silicone rubber sealing is constructed as explosion clap (relief pressure approximately 10 - 20 mbar) and equipped with turn-locks with adjustable spring pressure resistance.
On the rear side of the furnace the connection flanges for protective gas in- and outlet, vacuum and thermocouple.
The door flange as well as the connections for thermocouples and heating elements and gas outlet are water-cooled.
The inner housing is covered with fibre boards. The use of this lightweight, low heat storage material, permits extremely short heating up – and cooling down times.
The furnace is heated by exchangeable Kanthal-Super-1800 (KS1900 or Mo,(W)) heating elements, which are operated via a three-phase tyristor unit with phase-angle firing and a transformer. The heating element connections are being lead outside at the rear.
At the side, approximately in the middle of the furnace (installed from the back), a PtRh-Pt double thermocouple type S (Type B) (accuracy: class 2 according to DIN IEC part 2) measures the temperature. A pair of thermocouples is lead to the temperature controller and the one to the safety controller.
| 1 piece | lockable safety controller for additional protection of heating and insulation |
| 1 piece | 3-phase thyristorunit for phase angle firing |
| 1 piece | pre-transformer |
| 1 piece | operating hour counter |
| 3 pieces | ampere meter |
Linn High Therm is specialized in customizing its products to customer´s needs. Please let us know if you desire any modifications.
| model | liters | T max in °C | Inside dimensions mm (w x h x d) | kW |
|---|---|---|---|---|
| HT 1400 | 4,0 | 1400 | 130 x 190 x 160 | 3,5 |
| HT 1400 M | 12,5 | 1400 | 250 x 200 x 250 | 6,0 |
| HT 1400 G | 26,0 | 1400 | 250 x 350 x 300 | 9,0 |
| HT 1400 GT | 52,5 | 1400 | 250 x 700 x 300 | 16,0 |
| HT 1600 | 4,0 | 1600 | 130 x 190 x 160 | 3,5 |
| Product Line: | type series |
|---|---|
| Operation Mode: | Batch |
| Construction Type: | Furnace |
| Design: | Chamber furnace |
| Temperature Max (°C): | 1820 |
| Heating: | electrical |
| Heating Method: | resistance |
| Atmosphere: | Air |
| Applications: | annealing, brazing, calcination, calibration, crystal growing, firing, heat treatment, oxydation, reduction, sintering |
